PARTS CATALOG
PZE07K3SB, PZE09K3SB, PZE09R3SB, PZE12K3SB, PZE12R3SB, PZE15K3SB
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
46 67808077 EVAPORATOR DISTRIBUTOR
ASSY
PZE09K3SB 1
46 67808095 EVAPORATOR DISTRIBUTOR
ASSY
PZE09R3SB, PZE12R3SB 1
46 67812107 EVAPORATOR DISTRIBUTOR
ASSY
PZE12K3SB 1
46 67812112 EVAPORATOR DISTRIBUTOR
ASSY
PZE15K3SB 1
47 67808048 LEFT PANEL ALL 1
48.1 67808049 FRESH AIR FILTER GUIDE ALL 1
48.2 67808050 FRESH AIR FILTER LEVER ALL 1
49 67812176 SUPPORT BRACKETS PZE09K3SB, PZE12K3SB 1
49 67812169 SUPPORT BRACKETS PZE07K3SB, PZE09R3SB, PZE12R3SB, PZE15K3SB 1
50.1 67808051 FRESH AIR WIRE ALL 1
50.2 67808053 FRESH AIR DOOR BUSHING ALL 1
51 67808054 OUTDOOR MOTOR BRACKET ALL 1
52 67808055 FAN SHROUD TOP ALL 1
53 67808064 SEAL PLATE ALL 1
54 67808056 RIGHT CORNER POST ALL 1
55 67808057 LEFT CORNER POST ALL 1
56 67808058 BEARING SEAL PLATE ALL 1
57 67808059 INDOOR FOAM PAN ALL 1
58 67808060 FRESH AR DOOR CABLE HOLDER ALL 1
59 67808061 FRESH AIR DOOR ALL 1
60 67808073 ELECTRIC HEAT ELEMENT PZE07K3SB, PZE09K3SB, PZE12K3SB 1
60 67808086 ELECTRIC HEAT ELEMENT PZE09R3SB, PZE12R3SB 1
60 67808062 ELECTRIC HEAT ELEMENT PZE15K3SB 1
61 67808068 CONDENSER CAPILARY ASSY PZE07K3SB 1
61 67812177 CONDENSER CAPILARY ASSY PZE09K3SB 1
61 67808098 CONDENSER CAPILARY ASSY PZE09R3SB 1
61 67812108 CONDENSER CAPILARY ASSY PZE12K3SB 1
61 67808096 CONDENSER CAPILARY ASSY PZE12R3SB 1
61 67812113 CONDENSER CAPILARY ASSY PZE15K3SB 1
-63 67812089 SADDLE CLIP ALL 1
-64 67812171 COMPRESSOR HARNESS ALL 1
65 67812091 DISPLAY PCB ALL 1
--66 67808063 POWER CORD FASTENER PZE07K3SB, PZE09K3SB, PZE09R3SB, PZE12K3SB, PZ-
E12R3SB
1
-66 67812114 POWER CORD FASTENER PZE15K3SB 1
-67 67812093 DISPLAY ESCUTCHEON ALL 1
-68 67812094 ROOM TEMP SENSOR ALL 1
Figure 901
