Friedrich VERT-I-PAK Series Engineer's Manual

8
EXTENDED COOLING PERFORMANCE
OUTDOOR DRY BULB TEMP. (DEGREES F AT 40% R.H.)
75 85 95 105 110
INDOOR WET BULB TEMP. (DEGREES F AT 80 F D.B.)
72 67 62 72 67 62 72 67 62 72 67 62 72 67 62
VHA09K
BTUH 11054 10631 9842 10528 9926 9156 10114 9400 8319 9475 8413 7417 8954 7835 6914
WATTS 738 750 758 805 813 823 905 905 905 978 977 980 1023 1022 1026
AMPS 3.6 3.6 3.6 3.8 3.8 3.9 4.3 4.3 4.3 4.6 4.6 4.6 4.8 4.8 4.9
SHR 0.53 0.72 0.96 0.54 0.74 0.98 0.54 0.77 0.99 0.55 0.81 0.99 0.57 0.84 0.99
VHA12K
BTUH 14347 13798 12773 13664 12883 11883 13127 12200 10797 12298 10919 9626 11621 10169 8973
WATTS 996 1011 1022 1085 1096 1109 1220 1220 1220 1319 1318 1321 1379 1378 1383
AMPS 4.7 4.7 4.8 5.1 5.1 5.1 5.7 5.7 5.7 6.1 6.1 6.2 6.4 6.4 6.4
SHR 0.51 0.70 0.94 0.52 0.72 0.96 0.53 0.75 0.96 0.54 0.79 0.97 0.55 0.82 0.96
VHA18K
BTUH 21403 20584 19055 20384 19219 17727 19583 18200 16107 18346 16289 14360 17336 15170 13386
WATTS 1489 1513 1529 1622 1639 1659 1825 1825 1825 1973 1971 1976 2062 2061 2069
AMPS 7.1 7.2 7.2 7.7 7.7 7.7 8.6 8.6 8.6 9.3 9.3 9.3 9.7 9.7 9.7
SHR 0.46 0.62 0.84 0.47 0.65 0.86 0.47 0.67 0.86 0.48 0.71 0.87 0.49 0.73 0.86
VHA24K
BTUH 27048 26013 24081 25760 24288 22402 24748 23000 20355 23184 20585 18147 21908 19171 16917
WATTS 2062 2095 2118 2247 2269 2297 2527 2527 2527 2732 2729 2737 2856 2854 2864
AMPS 9.0 9.1 9.2 9.7 9.8 9.8 10.8 10.9 11.0 11.7 11.7 11.8 12.3 12.3 12.3
SHR 0.48 0.65 0.88 0.49 0.68 0.89 0.49 0.70 0.90 0.50 0.74 0.90 0.52 0.76 0.90
VHA09R
BTUH 11054 10631 9842 10528 9926 9156 10114 9400 8319 9475 8413 7417 8954 7835 6914
WATTS 747 759 767 813 822 832 915 915 915 989 988 991 1034 1033 1037
AMPS 2.9 2.9 2.9 3.1 3.1 3.2 3.5 3.5 3.5 3.8 3.8 3.8 3.9 3.9 4.0
SHR 0.53 0.72 0.96 0.54 0.74 0.98 0.54 0.77 0.99 0.55 0.81 0.99 0.57 0.84 0.99
VHA12R
BTUH 14582 14024 12983 13888 13094 12078 13342 12400 10974 12499 11098 9784 11811 10335 9120
WATTS 1012 1028 1039 1102 1114 1127 1240 1240 1240 1340 1339 1343 1401 1401 1406
AMPS 4.2 4.2 4.3 4.5 4.6 4.6 5.1 5.1 5.1 5.5 5.5 5.5 5.7 5.7 5.8
SHR 0.53 0.72 0.96 0.54 0.74 0.98 0.54 0.77 0.99 0.55 0.81 0.99 0.57 0.84 0.99
VHA18R
BTUH 21168 20358 18846 20160 19008 17532 19368 18000 15930 18144 16110 14202 17145 15003 13239
WATTS 1481 1505 1521 1614 1630 1650 1815 1815 1815 1962 1960 1966 2051 2050 2057
AMPS 6.3 6.3 6.4 6.8 6.8 6.8 7.6 7.6 7.6 8.2 8.2 8.2 8.6 8.6 8.6
SHR 0.45 0.61 0.83 0.46 0.64 0.84 0.46 0.66 0.85 0.48 0.70 0.85 0.49 0.72 0.85
VHA24R
BTUH 26460 25448 23558 25200 23760 21915 24210 22500 19913 22680 20138 17753 21431 18754 16549
WATTS 2020 2052 2074 2200 2223 2250 2475 2475 2475 2675 2673 2680 2797 2796 2805
AMPS 8.0 8.1 8.2 8.6 8.7 8.7 9.7 9.7 9.7 10.4 10.4 10.5 10.9 10.9 11.0
SHR 0.48 0.65 0.88 0.49 0.68 0.89 0.49 0.70 0.90 0.50 0.74 0.90 0.52 0.76 0.90
RATING
POINT
AHRI
390
