SMALL CHASSIS ELECTRICAL DATA

ELECTRICAL DATA

VHA09K VHA12K

HEATER WATTS 2500/2050 3400/2780 5000/4090 2500/2050 3400/2780 5000/4090

VOLTAGE 230/208

ELECTRIC HEATING BTU 8500/7000 11600/9500 17000/13900 8500/7000 11600/9500 17000/13900

HEAT CURRENT (AMPS) 10.9/9.9 14.8/13.4 21.7/19.7 10.9/9.9 14.8/13.4 21.7/19.7

HEATING AMPS HP 4.0/4.0 4.0/4.0 4.0/4.0 5.7/5.9 5.7/5.9 5.7/5.9

MINIMUM CIRCUIT AMPACITY 15 19.9 28.7 15 19.9 28.7

BRANCH CIRCUIT FUSE (AMPS) 15 20 30 15 20 30

LRA-COMPRESSOR (AMPS) 21 21 21 30 30 30

COOLING CURRENT (AMPS) 4.3/4.3 4.3/4.3 4.3/4.3 5.9/5.7 5.9/5.7 5.9/5.7

BASIC HEATER SIZE 2.5KW 3.4KW 5.0KW 2.5KW 3.4KW 5.0KW

POWER CONNECTION HARD WIRED HARD WIRED

RECOMMENDED BRANCH

CIRCUIT WIRE SIZES

*AWG- AMERICAN WIRE GAUGE

14 12 10 12 12 10

ELECTRICAL DATA

VHA09R VHA12R

HEATER WATTS 2500 3400 5000 2500 3400 5000

VOLTAGE 265

ELECTRIC HEATING BTU 8500 11600 17000 8500 11600 17000

HEAT CURRENT (AMPS) 9.4 12.8 18.8 9.4 12.8 18.8

HEATING AMPS HP 3.2 3.2 3.2 4.5 4.5 4.5

MINIMUM CIRCUIT AMPACITY 13.14 17.38 24.93 13.14 17.38 24.93
