LARGE CHASSIS ELECTRICAL DATA
ELECTRICAL DATA
VHA18K VHA24K
HEATER WATTS 2500/2050 3400/2780 5000/4090 2500/2050 3400/2780 5000/4090 7500/6135 10000/8180
VOLTAGE 230/208
ELECTRIC HEATING BTU 8500/7000 11600/9500 17000/13900 8500/7000 11600/9500 17000/13900 25600/20900 34100/27900
HEAT CURRENT (AMPS) 10.9/9.9 14.8/13.4 21.7/19.7 10.9/9.9 14.8/13.4 21.7/19.7 32.6/29.5 43.5/39.3
HEATING AMPS HP 7.8/8.3 7.8/8.3 7.8/8.3 8.5/9.4 8.5/9.4 8.5/9.4 8.5/9.4 8.5/9.4
MINIMUM CIRCUIT AMPACITY 14.3 19.2 27.8 17.2 22.1 30.7 44.3 57.8
BRANCH CIRCUIT FUSE (AMPS) 15 20 30 25 25 35 45 60
LRA-COMPRESSOR (AMPS) 42 42 42 46 46 46 46 46
COOLING CURRENT (AMPS) 9.2/8.6 9.2/8.6 9.2/8.6 10.4/10.0 10.4/10.0 10.4/10.0 10.4/10.0 10.4/10.0
BASIC HEATER SIZE 2.5KW 3.4KW 5.0KW 2.5KW 3.4KW 5.0KW 7.5KW 10.0 KW
POWER CONNECTION HARD WIRED HARD WIRED
RECOMMENDED BRANCH
CIRCUIT WIRE SIZES
*AWG- AMERICAN WIRE GAUGE
14 12 10 10 10 10 6 4
ELECTRICAL DATA
VHA18R VHA24R
HEATER WATTS 2500 3400 5000 5000 7500 10000
VOLTAGE 265
ELECTRIC HEATING BTU 8500 11600 17000 17000 25600 34100
HEAT CURRENT (AMPS) 9.4 12.8 18.9 18.9 28.3 37.7
HEATING AMPS HP 6.9 6.9 6.9 8.1 8.1 8.1
MINIMUM CIRCUIT AMPACITY 12.3 16.6 24.2 27.1 38.9 50.7
BRANCH CIRCUIT FUSE (AMPS) 15 20 30 30 40 55
LRA-COMPRESSOR (AMPS) 42 42 42 46 46 46
COOLING CURRENT (AMPS) 7.6 7.6 7.6 9.7 9.7 9.7
BASIC HEATER SIZE 2.5KW 3.4KW 5.0KW 5.0KW 7.5KW 10.0KW
POWER CONNECTION HARD WIRED HARD WIRED
RECOMMENDED BRANCH
CIRCUIT WIRE SIZES
*AWG- AMERICAN WIRE GAUGE
14 12 10 10 6 4
