4
Unit Description
Unit Description & Accessories Included
2009 Electrolux Home Products, Inc. All rights reserved.
Accessories Included
CONTROL PANEL
REMOTE CONTROL
ROOM AIR DISCHARGE
CASTOR
CARRYING HANDLE
(BOTH SIDES)
REMOTE CONTROL
STORAGE DOOR
Fig. 1
EXHAUST
AIR OUTLET
AIR INTAKE
DEHUMIDIFYING
DRAIN OUTLET
BOTTOM TRAY DRAIN OUTLET
EXHAUST HOSE
(STORAGE WHEN
NOT IN USE)
EXHAUST
ADAPTOR A
Fig. 2
Check all the accessories are included in the package and please refer to the installation
instructions for their usage.
PARTS: PARTS NAME: QUANTITY:
Exhaust hose
Unit/ Exhaust Adaptor A
Window/ Exhaust Adaptor B
Window Sliding Kit
Foam Seal
Remote Control
Battery(For remote control)
1 pc
1 set
1 pc
1 pc
3 pcs
1 pc
2 pcs
To Next Page
