Section 6 Wiring Diagrams
6-1
WP
DP
Dispenser
RD+YE
BK
BK
BK
BK
WH+RD
WH+RD
WH
WH+RD
WH+RD
WH+RD
WH+RD
WH+RD
YE
Inlet
Valve
Pressure
Switch
Rinse Aid
3
2
1
PK
OR
VT
BK
WH
BU
BU
RD
Drain Pump
Wash Pump
NTC
Heater Thermostat
10
9
8
7
6
5
4
3
2
2
1
1
P3
P2
P1
P4
P8
P1
Display
and
Button
Electronic
Control
Board
Door
Switch
GR
L
N
E
120V/60HZ
