TOOLS YOU WILL NEED:
¨ Phillips head screwdriver
¨ 5/16" and 1/4" nutdriver
¨ 6" Adjustable wrench
¨ Level
¨ Carpenters square
¨ Measuring tape
¨ Safety glasses
¨ Flashlight
¨ Bucket to catch water when flushing
the line
¨ Gloves
For New Installations Only:
¨ Tubing cutter
¨ Drill and appropriate bits
¨ Hole saw set
Installation Preparation
PARTS SUPPLIED:
¨ Two #8 Phillips flat head wood screws, 5/8” long to
secure dishwasher to underside of countertop (in
literature package).
¨ Two Phillips head, color matched toekick screws (in
literature package).
MATERIALS YOU WILL NEED:
¨ Ferrule, compression nut and 90° Elbow (3/
8”NPT external thread on one end, opposite
end sized to fit water supply)
¨ Thread seal tape
¨ UL Listed wire nuts (3)
Materials for New Installations Only:
¨ Air gap for drain hose, if required
¨ Waste tee for house plumbing, if applicable
¨ Electrical cable or power cord, if applicable
¨ Screw type hose clamps
¨ Strain relief for electrical connection
¨ Hand shut-off valve
¨ Water line 3/8” min. copper
¨ Coupler for extending drain line, if applicable
90° Elbow,
Ferrule and
Compression
Nut
Wire Nuts (3)
Waste Tee
Electrical Cable
(or Power Cord, if
applicable)
Hot Water line
Screw Type
Hose
Clamps
Coupler
Hand
Shut-Off
Valve
2 Wood Screws
Hole Saw Set
Measuring Tape
Tubing
Cutter
1/4"
and 5/16"
Nutdriver
Safety
Glasses
6"
Adjustable
Wrench
Bucket
Flashlight
Gloves
Carpenters
Square
Level
Thread
Seal
Tape
Air Gap
Strain Relief
2 Color Matched
Toekick Screws
Drill and
Bits
Phillips
Head
Screwdriver
Screw Type
Hose Clamp
