11 INSTALLATION INSTRUCTIONS & AIR CONDITIONER FEATURES
6.Cut the foam seal B to an appropriate
length and seal the open gap between the
sliding sash and outer window sash, as
shown in Fig.15.
Fig.15
Foam seal B
Fig.16
7.To secure sliding sash in place, attach right
angle sash lock with 1/2" (12.7mm) screw as
shown(Fig.16).
3.Close the window sash securely against
the window slider kit.(Fig.14)
4.Drive two 1/2" screws to secure the
window slider kit to the window
sash.(Fig.14)
5.Drive two 3/4" screws to secure the
window slider kit to the window sill.(Fig.14)
Fig.14
window sill
Window slider kit
3/4" screws
1/2" screws
