12
INSTALLING THE HOOD
INSTALL RANGE HOOD
(Recirculating version)
Lift the range hood up under cabinet and determine
 ¿QDOORFDWLRQE\FHQWHULQJEHQHDWKFDELQHW0DUNRQ
the underside of cabinet the location of the 4 keyhole
mounting slots on the range hood (See slots
dimensions on page 6). Set range hood aside on a
covered surface.
8VHï»8” (3 mm) drill bit and drill 4 pilot holes as shown.
NOTE: Make the drill holes on the thin area of the slot.
,QVWDOOWKHFP[FPPRXQWLQJVFUHZVLQ
pilot holes. Leave about ¼” (6.4 mm) space between
screw heads and cabinet to slide range hood into place.
Power Supply Cable Installation
For direct wire installations, run the home power
supply cable according to the National Electric Code
or CSA standards and local codes and ordinances.
There must be enough wiring from the fused disconnect
 RUFLUFXLWEUHDNHUER[WRPDNHWKHFRQQHFWLRQLQWKH
 KRRGHOHFWULFDOWHUPLQDOER[
NOTE
Do not reconnect power until the installation is
complete.
Remove the screw from the
 WHUPLQDOER[FRYHU
 5HPRYHWHUPLQDOER[FRYHU
and set aside.
1.
2.
3.
1.
2.
A
A. Keyhole slot
A
ï»´
(6.4 mm)
A
A. Drill pilot hole
A
B
A. Terminal box cover
B. Screw
MAKE ELECTRICAL CONNECTION
WARNING
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before operating.
Failure to do so can result in death or electrical shock.
1. Disconnect power.
2. Use UL listed wire connectors and connect white wires
(A) together.
3. Use UL listed wire connectors and connect black wires
(B) together.
WARNING
Fire Hazard
Electrically ground the blower. Use copper wire.
Connect ground wire to green ground screw in
WHUPLQDOER[)DLOXUHWRGRVRFDQUHVXOWLQGHDWK
¿UHRUHOHFWULFDOVKRFN
4. Connect green (or bare) ground wire from power supply
WRJUHHQJURXQGVFUHZLQWHUPLQDOER[DQGVHFXUHO\WLJKWHQ
,QVWDOOWHUPLQDOER[FRYHU
6. ,QVWDOOWKH:PD[,QFDQGHVFHQWOLJKWEXOE6HH
“Replacing the Incandescent Light Bulb” in the “Range
Hood Care” section.
7. Reconnect power.
Complete Installation
5HSODFHJUHDVH¿OWHULIUHPRYHG6HHWKH³5DQJH+RRG
Care” section.
Check the operation of the range hood fan and light.
See “Range Hood Use” section.
If range hood does not operate, check to see whether a
circuit breaker has tripped or a household fuse has blown.
Disconnect power and check wiring connections.
NOTE
7RJHWWKHPRVWHI¿FLHQWXVHIURP\RXUQHZ
range hood, read the “Range Hood Use” section.
1.
2.
A
B
C
D
E
F
G
A.White wires
B. Black wires
C. UL listed wire connector
D. Green (or bare) ground wire
E. Home power supply cable
F. UL listed or CSA approved
½” strain relief
G. Green ground screw
