Page 33
Display Will Not Illuminate
Possible component failure:
1. Control Board
2. Display
Display Will Not Illuminate
Measure the voltage between
the two outside pins of the
display plug.
5 VDC
Defective
Display.
Zero
Defective control
board
P8
P3 - 5
