Page 35
Readings Pots & Pans 2000 Ohms
Normal 10000 Ohms
Short Wash 20000 Ohms
Rinse & Hold 3000 Ohms
Dishwasher Operates in Normal
Wash No Matter What Cycle is
Selected (Selectronic models only).
Set the selector to "Pots & Pans." Drop the
control panel, unplug the cycle selector control
from the control board. Measure the resistance
between pins 1 and 3 in the plug.
Infinity
Defective cycle
selector control.
47,000 Ohms
Measure the resistance between the
black lead and center lead for each
setting.
Defective control
board.
Infinity
Defective cycle
selector control.
To Next Page
