Page 44
Dishes Are Not Dry
Is the heat dry switch on?
Run diagnostic test for heater,
vent and blower. Does the
heating element heat.
No
Yes
Turn switch
to "ON."
No
Remove the door panel and
kick plate. Check the voltage
drop between the terminals of
the heating element.
120 Volts
Defective heating
element.
0 Volts
Open the control panel. Check
the voltage drop between
terminal PT02 on the control
board and neutral.
0 Volts
Defective control
board.
Yes
Is the vent
valve open.
Open the control panel.
Check the voltage drop
between the terminals of
the vent actuator.
No
120 Volts
Defective
vent actuator.
0 Volts
Defective
control
board or
broken wire.
Yes
Is the blower
running?
Yes
Check water
temperature.
Defective
blower
motor.
No
Defective Hi-
Limit Thermostat.
120 Volts
NOTE: This dishwasher will
not operate properly
unless the incoming
water temperature is
above 120°F.
