Frigomatic Milano Manual v1 PAGE 3
CHAPTER 1
THE FRIGOMATIC MILANO 12/24V REFRIGERATION SYSTEM
The "Frigomatic Milano" system consists of the following components:
1) The condensing unit:
Milano A Air cooled
Milano K Keel cooled
Milano W Water cooled
2) The thermostat
Fridge or Freezer mechanical thermostat
Optional:
Full range mechanical Air sensing thermostat
Digital thermostat
(contact Penguin at
sales@penguinfrigo.co.uk for separate manual)
3) The aluminium evaporator
Type F Plate evaporator can be bent to suit the box
(contact sales@penguinfrigo.co.uk for details on bending if required)
Type H Ice box
Type B Freezer box evaporator
4) The water pump and relay or ump interface (mod. Milano W only).
5) The keel cooler heat exchanger (mod. Milano K only)
