Frog Pool FroG 5400 - POOL FROG Cycler Maintenance; Replacing the Control Dial O-Rings; Replacing Cap O-Ring; Replacing Knobs

15
1.
2.
3.
4.
5.
1.
2.
3.
6.
7.
®
B
R
AN
D
CYCLER
REPLACEMENT PARTS FOR OFF-LINE Model 5430
REF. # PART NUMBER DESCRIPTION
11* 01-22-8620 2” x 1/2” Bushing
12 01-22-7800 90° Elbow
13 01-22-7690 Small Clamp
14 01-22-7700 6’ PVC Tubing
15 01-22-7850 Scoop Gasket
16 01-22-7790 Venturi Scoop
17 01-22-7910 Scoop Clamp
POOL FROG
®
Cycler Maintenance
S
I
L
I
C
O
N
E
L
U
B
R
I
C
A
N
T
S
I
L
I
C
O
N
E
L
U
B
R
I
C
A
N
T
Using a needle nose pliers, nd
the snap ring tail located at
approximately the ve o’clock
position under the control dial.
Pull down and out of the groove.
Using a large screwdriver, loosen
the control dial. Carefully pry the
dial until it pulls out.
Carefully replace the rubber
o-ring without stretching it. Apply
silicone lubricant, that came
with your POOL FROG
®
Cycler, on
o-ring.
Push control dial completely into
the housing and turn the dial to
setting 2.
Insert the non-lipped end of snap
ring into the groove opening
beginning at the 5 o’clock position
and push it up so that it threads
itself around the control dial.
Using a small screwdriver or
pointed tool to help guide it, make
sure the snap ring stays in the
groove as it is inserted.
Lubricate o-ring every couple of
months with silicone lubricant
that came with your POOL
FROG
®
Cycler. DO NOT USE
petroleum based lubricants.
Replacing the Control Dial O-Rings
Replacing Cap O-Ring
Replacing Knobs
Back of Cycler
Top of Cap
Place o-ring in bottom half of
groove.
Place your thumbs on each
side of the cap over the o-ring
in the groove.
Roll your thumbs back and
forth over the o-ring while
pushing upward until the
o-ring falls into the top of the
groove.
Bottom half
of groove
Top half of
groove
Bottom half
of groove
Top half of
groove
Replace knob in back or on
cap of POOL FROG
®
Cycler
by unscrewing old one and
screwing in new one.
Product # 01-22-9971
