Fromm A335 - Page 9

[ ] = Group * = Wearing parts
9
13278001.een.fm
N1.3203 1 SOCKET SET SCREW M4 X 8 C3
N1.5131 1 HEXAGON NUT M5 B6
N1.5907 1 HEXACON NUT M6 B3
N1.6103 2 WASHER 5.3 X 9.5 X 1 C3
N1.6135 1 WASHER 15.2 X 24 X 1 C6
N2.1108 1 SECURITY RING E20 B1
N2.1117 1 SECURITY RING E14 C6
N2.2136 A33.1192 2 PARALLEL PIN 4 H6 X 10 E5
N2.2143 A33.1192 1 PARALLEL PIN 5 H6 X 16 D3
N2.2147 1 PARALLEL PIN 3 M6 X 10 E4
N2.2148 A33.1192 1 PARALLEL PIN 14 H6 X 48 D3
N2.2148 1 PARALLEL PIN 14 H6 X 48 B3
N2.2149 2 PARALLEL PIN 4 H6 X 22 E4
N2.2150 1 PARALLEL PIN 10 H6 X 65 B6
N2.2165 1 PARALLEL PIN 4M6 X 34 C5
N2.2230 1 PARALLEL PIN 5 H8 X 60 C3
N2.2401 1 DOWEL PIN 3 X 10 E5
N2.2441 2 DOWEL PIN 6 X 20 MM B5
N2.2603 1 GROOVED PIN 6 X 16 A3
N2.3205 1 WOODRUFF KEY 5 X 7,5 X 18,57 B2
N2.4902 2 HAMMER HEAD BOLT 1,85 X 4,76 B4
N2.4906 1 HAMMER HEAD BOLT 5,31 X 12,7 B5
N2.5154 6 PRESSURE SPRING 0.45 X 3.9 X 7 B2
N2.5170 1 PRESSURE SPRING 2 X 9.8 X 96 B5
N2.5171 1 PRESSURE SPRING 1 X 8 X 26 C5
N2.5606 1 CUP SPRING 40X20.4X1 B2
N2.5807 1 TORSION SPRING C3
N3.2315 1 NEEDLE BEARING B3
N3.2316 1 NEEDLE BUSH C6
N3.3131 A33.1192 2 SLIDE-BEARING D4+
N3.3131 2 SLIDE-BEARING C5+
N41.9128 1 ADHESIVE LABEL A5
N41.9132 1 LABEL A335 B4
N4.1116 2 GRIP BALL A3+
13.2780.01 A335/13/0.50-0.58 A335.0008.01 29.11.99
Item-No. in group Pcs. Description Dimension Field
