Fromm A335 - Spare Parts List

[ ] = Group * = Wearing parts
8
13278001.een.fm
7 SPARE PARTS LIST 13.2780.01
13.2780.01 A335/13/0.50-0.58 A335.0008.01 29.11.99
Item-No. in group Pcs. Description Dimension Field
A33.1120
*
1 SHEAR BLADE D5
A33.1137
*
1 DIE HALF E3
A33.1138
*
1 DIE HALF E3
A33.1155 1 SEALING HANDLE A4
A33.1158 1 STOP C3
A33.1161 1 BUSH C3
A33.1163 1 SOCKET SET SCREW C5
A33.1167 A33.1192 1 ROLLER D4
A33.1168 A33.1192 1 LINK D4
A33.1170 1 EJECTOR A5
[A33.1173] 1 SHIM C3
A33.1174 1 COVER C6
A33.1176 1 WASHER B4
A33.1177 1 WASHER B5
A33.1179 1 TRUNNION B3
A33.1181 1 SEALING CAM B5
[A33.1186] 1 HOUSING C5
[A33.1187] A33.1192 1 DIE AND CUTTER SUPPORT D3
A33.1190 1 COVER C6
[A33.1192] 1 DIE AND CUTTER SUPPORT D3
A33.2121
*
1 PUNCH E3
A33.2159 1 STRAP STOP D5
A33.2163 1 LIMIT BOLT D3
A33.2174 1 BASE PLATE E5
A33.2177
*
1 GRIPPER HSS E5
A33.3110 3 TENSIONING PAWL B2
A33.3124 2 RING HALF B2
A33.3129 1 ROCKER B6
A33.3130 1 LOCKING RING B3
A33.3131 1 DRIVER B2
A33.3134 1 STRAP GUIDE C5
A33.3137
*
3 CATCH PAWL B2
A33.3138 1 SPACER RING C5
A33.3143
*
1 TENSIONING WHEEL C5
[A33.3144] 1 TENSION SHAFT B2
A33.3151 1 TENSION HANDLE A3
N1.1104 1 SCREW M8 X 20 E4
N1.1110 1 SCREW M5 X 8 D5
N1.1165 A33.1186 1 SCREW M8 X 10 B3
N1.1168 2 SCREW M5 X 16 C3
N1.1181 2 SCREW M5 X 12 D5
N1.1182 1 SCREW M10 X 1 X 80 B3
N1.1184 1 SCREW M12 X 1,25 X 80 B5
N1.1202 1 SCREW M5 X 10 B4
N1.1210 1 SCREW M6 X 25 B2
N1.1304 2 SCREW M3 X 8 E4
N1.1806 4 SCREW M4 X 10 D4+
N1.1808 4 SCREW M4 X 10 D6
N1.3106 1 SOCKET SET SCREW M5 X 6 E3
N1.3116 1 SOCKET SET SCREW M5 X 25 B6
N1.3120 1 SOCKET SET SCREW M12 X 12 C3
