[ ] = Group * = Wearing parts
11
13462001.een
A48.2213 A48.0104 1 END COVER E4
A48.2215 A48.0104 1 WORM C7
[A48.2217] A48.0103 1 HOSE D6
[A48.2303] 1 SUSPENSION BRACKET D1
[A48.2304] A48.2303 1 SUSPENSION BRACKET E1
A48.2306 A48.2303 1 FLANGE SHAFT E2
[L2.1103] L2.1108 1 PLANET SHAFT --
[L2.1108] 1 AIR MOTOR D7
L2.1201 L2.1108 1 EXHAUST RING --
L2.1203 L2.1212 1 PLASTIC JACKET --
[L2.1212] L2.1108 1 HOUSING --
[L2.1223] L2.1108 1 PLANET SHAFT --
L2.1301 L2.1323 1 END PLATE --
L2.1302 L2.1323 1 PARALLEL PIN --
L2.1303 L2.1323 1 CYLINDER --
L2.1304
*
L2.1323 5 VANE --
L2.1305 L2.1323 1 ROTOR --
L2.1308 L2.1108 1 DAMPER --
L2.1309 L2.1103 1 PLANET SHAFT --
L2.1310 L2.1103 2 NEEDLE CAGE --
L2.1311 L2.1103 2 SPUR WHEEL --
L2.1312 L2.1103 2 SHAFT --
L2.1313 L2.1108 1 BEARING RING --
L2.1314 L2.1323 1 END PLATE --
[L2.1323] L2.1108 1 MOTOR CELL --
L2.1402 L2.1223 32 BEARING NEEDLE --
L2.1403 L2.1223 2 SPUR WHEEL --
L2.1404 L2.1223 2 SHAFT --
L2.1405 L2.1108 1 BEARING RING --
L2.1408 L2.1223 1 PLANETARY CAGE --
L2.1409 L2.1413 1 AIR INLET RING --
L2.1410 L2.1413 1 TENSION SCREW --
L2.1411 L2.1413 1 THROTTLE HEAD --
L2.1412 L2.1413 1 THROTTLE SCREW --
[L2.1413] L2.1108 1 AIR INLET HEAD --
L2.1505 L2.1323 1 KEY --
N1.1106 A48.2303 2 SCREW M6 X 20 E2
N1.1114 A48.0104 2 SCREW M5 X 25 E3
N1.1128 2 SCREW M8 X 60 B1
N1.1521 A48.0104 1 HEXAGON SCREW M5 X 16 D5
N1.1813 2 RAISED CTRS. HEAD SCREW M5 X 16 A4+
N1.1814 7 RAISED CTRS. HEAD SCREW M5 X 25 A4+
N1.1815 2 RAISED CTRS. HEAD SCREW M6 X 25 B4
N1.1816 A48.0104 2 RAISED CTRS. HEAD SCREW M4 X 16 C7
N1.2108 A48.0104 2 COUNTERSUNK SCREW M6 X 16 C4
N1.2109 A48.0104 1 COUNTERSUNK SCREW M5 X 10 D5
N1.2140 A48.0102 1 COUNTERSUNK SCREW M5 X 45 D4
N1.2141 1 COUNTERSUNK SCREW M8 X 30 B5
N1.2212 A48.0103 1 COUNTERSUNK SCREW M4 X 25 C3
N1.2215 A48.0103 1 COUNTERSUNK SCREW M4 X 30 C3
N1.5130 A48.2303 2 HEXAGON NUT M10 D1
N1.5131 A48.0104 1 HEXAGON NUT M5 D5
N1.5302 A48.0102 1 RETAINING NUT M5 C1
13.4620.01 A482/19/0.80/ULT/7.0 A482.0001.01 22.12.10
Item-No. in group Pcs. Description Dimension Field
To Next Page
