Fromm A482 - Page 12

[ ] = Group * = Wearing parts
12
13462001.een
N1.6206 2 SPRING LOCK WASHER M8 B1+
N1.6207 A48.0104 2 SPRING LOCK WASHER M5 E3+
N1.6220 A48.2303 2 SPRING LOCK WASHER M6 E2
N2.1202 L2.1108 1 SECURITY RING J32 --
N2.2115 A48.0104 1 PARALLEL PIN 6 m6 X 20 D4
N2.2172 A48.0104 2 PARALLEL PIN 5 m6 X 30 E3+
N2.3205 A48.0104 1 WOODRUFF KEY 5 X 7.5 X 18.57 C7
N2.4902 4 HAMMER HEAD BOLT 1.85 X 4.76 --
N2.5102 A48.0103 1 PRESSURE SPRING 0.6 X 8 X 14/6 B3
N2.5151 A48.0103 1 PRESSURE SPRING 0.3 X 2.8 X 11/11.5 B4
N2.5159 A48.0103 1 PRESSURE SPRING 0.5 X 7 X 18/7.5 C3
N2.5161 A48.0103 1 PRESSURE SPRING 1 X 12 X 20/6.5 B3
N2.5195 1 PRESSURE SPRING 3.6 X 63.6 X 140/6.5
(LINKS)
A2
N2.5196 1 PRESSURE SPRING 4.5 X 82.5 X 160/6.5
(LINKS)
B5
N2.5216 1 PRESSURE SPRING 1.6 X 9.6 X 76/25.5 B4
N2.5604 A48.2303 2 CUP SPRING 31.5 X 16.3 X 1.25 D1
N3.1102 L2.1108 4 BALL BEARING 15 X 32 X 9 --
N3.1108 L2.1323 1 BALL BEARING 6 X 19 X 6 --
N3.1109 L2.1323 1 BALL BEARING 8 X 22 X 7 --
N3.1131 A48.0104 1 BALL BEARING 12 X 32 X 10 D7
N3.1706 A48.0103 1 BALL 15 MM B3
N3.1708 A48.0103 1 BALL 10 MM B3
N3.2313 A48.0104 1 NEEDLE CASE 12 X 18 X 12 C5
N3.2342 A48.0104 1 NEEDLE CASE 17 X 23 X 12 C7
N3.2343 A48.0104 1 NEEDLE BUSH 17 X 23 X 12 D5
N3.2405 A48.0104 1 INNER RACEWAY 12 X 16 X 16 D4
N3.2608 A48.0104 1 PACKING RING 17 X 23 X 3 E5
N3.3144 A48.0104 1 SLIDE-BEARING 15 X 17 X 23 X 17 E4
N3.4108 A48.0104 1 THRUST BEARING CAGE 17 X 30 X 2 C6
N3.4311 A48.0104 2 THRUST RACE 17 X 30 X 1 C7
N41.9128 1 ADHESIVE LABEL 30 X 10 X 0.1 --
N41.9129 1 ADHESIVE LABEL p max. 6 bar/87 psi --
N4.9137 1 NUMBER PLATE <<A482>> --
N4.9159 1 LABEL <<CE>> --
N6.5133 A48.0103 1 REDUCING COUPLING B2
N6.5195 A48.0104 1 FITTING E7
N6.5624 A48.0103 1 ANGLE G 1/4 B2
N6.6204 A48.0103 2 O-RING 18 X 2 B2
N6.6217 A48.0103 2 O-RING 15 X 2 B3
N6.6230 A48.0103 1 O-RING 8 X 1.5 B3
N6.6234 L2.1413 1 O-RING 7.1 X 1.6 --
N6.6235 1 O-RING 12 X 2 A3
N6.6235 A48.0103 1 O-RING 12 X 2 B2
N6.6253 A48.0104 1 O-RING 42 X 1,5 C7
N6.6505 L2.1413 1 FLAT SEAL 21 X 17 X 1,5 --
N7.1205 A48.0104 2 SEALING DISK 18 E3
13.4620.01 A482/19/0.80/ULT/7.0 A482.0001.01 22.12.10
Item-No. in group Pcs. Description Dimension Field
