Fromm P324 - Page 26

[ ] = Group * = Wearing parts
26
43062301.een.fm
P32.1422 P32.1414 1 LEVER D23
P32.2001 P32.0153 1 BODY A1+
[P32.2006] P32.0148 1 HANDLE LEVER C23
P32.2009 P32.2043 2 TURNING BUTTON C20
P32.2010 P32.0148 1 COVER A22
P32.2011 P32.0148 1 INSERTATION PART A22
P32.2012 P32.0147 1 GUIDE C16
P32.2015 P32.0150 1 SPUR WHEEL B23
P32.2016 P32.0147 1 SPUR WHEEL B18
P32.2017 P32.0153 1 SWIVEL SHAFT C2
P32.2018 P32.0151 1 CONICAL GEAR WHEEL C22
P32.2020 P32.0147 1 COVER B7
P32.2023 P32.0147 1 FIXING PLATE A9
P32.2024 P32.0148 1 PRESSURE BUTTON A21
[P32.2026] P32.0147 1 LEVER B7
P32.2030 P32.0148 1 DISK B22
P32.2032 P32.0147 1 HOOK C18
P32.2034 P32.0147 1 SHAFT C15
P32.2035 P32.0154 1 SPUR WHEEL A13
P32.2036 P32.0156 1 SPUR WHEEL C14
[P32.2040] P32.0148 1 MOTOR HOUSING D22
[P32.2042] P32.0148 1 MOTOR HOUSING B20
[P32.2043] P32.0148 1 CIRCUIT BOARD C21
P32.2063 P32.0152 1 DISK B23
P32.2064 P32.0152 1 STEEL SHEET B23
[P32.2065] P32.0152 1 ELECTRIC MOTOR B23
P32.2067 P32.0147 2 CENTERING SLEEVE A7
43.0623.01 P324/12.7/0.40-0.64 P324.0001.01 23.04.07
Item-No. in group Pcs. Description Dimension Field
