Connections and
mechanical com-
ponents: CU 800i
(3)
(4)
(5)
(1)
(2)
Front of cooling unit
(9)
(8)
(7)
(6)
Rear of cooling unit
(1) Coolant flow connection (blue)
(2) Coolant return connection (red)
(3) Screw cap for coolant tank
(4) Important notes on maintenance and operation
(5) Coolant viewing window
(6) Blanking cover
(7) Blanking cover
(8) Rating plate
(9) Power source connection
