Fronius IG 15 - Display Reading Schemes

22
Mode „Now“ Mode „Day“ / „Year“ / „Total“
output supplied
(W)
energy supplied
(kWh / MWh)
voltage
(V)
electricity supplied
(A)
mains frequency
(Hz)
* mains impedance
(Ohm)
module voltage
(V)
module power
(A)
* module temperature
(°C;alternatively also °F)
insulation resistance
(MOhm)
yield
(set applicable currency)
power output supplied (maxim.)
(W)
* energy as read by consumption
meter
(kWh / MWh)
CO
2
-reduction
(kg / t)
mains voltage (maximum)
(V)
* module temperature (maximum)
(°C; alternat. also °F)
mains voltage (minimum)
(V)
* module temperature (minimum)
(°C; alternat. also °F)
* output reading of consumption
meter
(W)
* ambient temperature
(°C; alternnatively also in °F)
* insolation
(W/m²)
* insolation (maximum)
(W/m²)
* ambient temperature(maximum)
(°C; alternat. also °F)
* ambient temperature( minimum)
(°C; alternat. also °F)
* time
(HH:MM)
Scheme of
display rea-
dings
The following scheme contains a brief list of the display readings available.
Display readings without footnote are shown when the setting „standard“
is chosen (factory setting).
* optional - if the required option card is not available, the message
„N.A.“ (nicht angeschlossen = not connected) is displayed.
module voltage (maximum)
(V)
operating hours of FRONIUS IG
unit
(HH:MM)
