Fitting the mounting
bracket (standard)
Important! The mounting bracket
must be fitted using an M8 shoul-
der screw and an M6 screw. After
screwing the mounting bracket in
place, another dowel pin (Ø6 mm)
must be driven in to secure it.
Important! Drill a Ø5.8 mm hole
for the mounting bracket and use a
reamer to enlarge the hole so it
can accommodate the dowel pin
(Ø6G7).
WARNING! Work perfor-
med incorrectly can cause
serious injury to people and
damage to property. This instal-
lation must only be carried out
by trained and qualified person-
nel. Observe the safety rules in
the power source operating
instructions.
