Fronius Symo 12.5-3-M Quick Start Guide

max. C 80 A
AC ~
RCD
National Standards
?
Type A
YES
I
N
≥100 mA
§


M32 (Ø 7-15mm) mounted
M32 (Ø 18-25 mm) mounted
M32 (Ø 7-15mm) enclosed
M32 (Ø 18-25 mm) mounted
10-12 kW:
15-17,5 kW:
20 kW:
AC~

2,5 - 10 mm²
10 - 25 mm²
D1
D2
D3
D1
D1
D1
15 mm
70 mm
D > 6 mm
DC-
*
DC =
DC1+ DC2+
*
min. 2,5 mm² - 16 mm²
DC Con Kit 25
6 - 25 mm²
DC Con Kit 35
> 16 - 35 mm²

DC=


PV 1
1
DC
DC
+1
+1
DC
DC
+2
+2
DC
DC
-
-
2
1 23456
312
+1 +2
PV 1
PV 2
DC-1
DC+1
DC-2
DC+2
* I
DC NENN
/ MPP
3

Fronius Symo 12.5-3-M Specifications

General

Dimensions	725 x 510 x 225 mm
Protection class	IP 66
Topology	Transformerless
Operating temperature range	-25°C to +60°C
Max. output current	18.1 A
THD	< 3%
Number of MPP trackers	2
Maximum Input Voltage	1000 V
Warranty	5 years
AC nominal output	12500 W
Max. apparent AC power	12500 VA
DC input voltage range	200 V - 1000 V
MPP voltage range	200 V - 800 V
AC nominal voltage	3 x 230 / 400 V
