General
General remarks
NOTE!
Observe the safety rules in the power source operating instructions at all times.
VR 1500 robot wirefeeder VR 1550 robot wirefeeder
Owing to its modular design, the robot wirefeeder can be extended as needed (e.g. Robac-
ta Drive, gas purging, torch support etc.)
The VR 1500 is available with different wire speeds:
- 11 m/min (433.07 ipm.)
- 12 m/min (472.44 ipm.)
- 22 m/min (866.14 ipm.)
- 30 m/min (1181.10 ipm.)
The VR 1550 is available with a wire feed speed of 22 m/min.
The motor plate and control unit can be installed and operated independently of each oth-
er. The control unit, however, must be earthed/grounded separately.
Application area The robot wirefeeder is specially designed for fitting to the robot arm and can be used in
conjunction with the TS 4000 / 5000, TPS 3200 / 4000 / 5000 power sources. The robot
wirefeeder is suitable for all standard shielding gases.
The VR 1500 - 11 and VR 1500 - 12 are also used for flux core wire applications.
The VR 1500 - 12 is primarily used for complex wirefeeding applications requiring a high
degree of torque:
- solid flux core wires up to 2.3 mm (0.13 in.) on large spools
- solid flux core wires up to 2.3 mm (0.13 in.) in welding wire drums
The VR 1500 - 30 is also used for flat wire applications.
In particular, the VR 1500 - 11, VR 1500 - 12 and VR 1500 - 30 are also used in conjunction
with the high performance TS / TPS 7200 and TPS 9000 power sources.
