FS0507T PN 60711000162
30 Battery status
20 Charged immediately
10 Power is low, machine
automatically enters low speed
mode
4.2 Safety device
4.2.1 Safety valve to prevent damage to hydraulic circuit.
It releases oil pressure in case oil parts are damaged when the oil in the circuit rising
too much.
4.2.2 Balanced valve.
Preventing lift cylinder shrinking as the hydraulic tube is broken so that the platform
falls freely.
4.2.3 Emergency falling valve.
Due to the failure of the supply pressure device, the device cannot be operated, so that
when the operator cannot get down, the valve can be used to lower the platform. The
platform can be lowered by opening the emergency lowering valve (turning
counterclockwise). This operation is only used in emergency situations, and it remains
closed under normal conditions (tightened clockwise).
4.2.4 Emergency stop button.
In the event of a dangerous situation, use this switch to stop all movements of the
machine. Pressing the switch will cut off all power to the machine. After solving the
problem, pull up the emergency stop button, and then you can release the emergency
stop. However, if the emergency stop button is released while the foot switch is
depressed, it will not work. You should temporarily release the foot switch and then
depress it again.
4.2.5 Tilt alarm
When the machine is installed in an inclined place and there is a danger of overturning,
this device can prevent overturning. Under the following conditions, the tilt alarm
