Frontier DH1276 - Page 16

* M/S - Model Specific Parts Catalog 13
Ref.#Part # Description Qty.
1 TL9757 MAIN FRAME, DH12 SERIES 1
2TLT-33 HITCH PIN, 7/8", CAT. I, W/ NUT & WASHER 2
3 TL15560 A-FRAME HITCH, 2
1
/2", RIGHT 1
3A TL15559 A-FRAME HITCH, 2
1
/2", LEFT 1
4 TL14993 STRUT, 29
3
/4", DH12 SERIES, RIGHT 1
4A TL15203 STRUT, 29
3
/4", DH12 SERIES, LEFT 1
5 TL9653 STRUT SPACER, 1
1
/2"1
6TLT-725 HEX BOLT, 5/8" x 3 3/4", GR. 5 1
7 TL12443 REAR ADJUSTING BAR, 18
1
/2"1
8 TL9690 ADJUSTING BAR PIN 2
9 TL9979 HAIR PIN CLIP 2
10 TLT-745 HEX BOLT, 5/8" X 5" GR. 2 20
11 TL12895 SLIDE PLATE TOP 2
12 TL12896 SLIDE PLATE BOTTOM 2
13 TL9192 HEX BOLT, 5/8"X21/2", GR. 5 2
14 TLT-22 5/8" HEX NUT 40
15 TLT-24 5/8" LOCK WASHER 40
16 TLT-56 BUSHING, 5/8"X31/16" 4
17 TL12444 FRONT ADJUSTING BAR, 22
1
/2"1
18 TL15189 ASSEMBLY MANUAL TUBE AND CAP 1
19 TL15214 HEX BOLT, 5/16" X 1
1
/4" GR. 2 2
20 TLT-163 REAR GANG BEAM 3" X 3" X 33" MODEL DH1276 2
TLT-632 REAR GANG BEAM 3" X 3" X 37" MODEL DH1280 2
TLT-635 REAR GANG BEAM 3" X 3" X 48" MODEL DH1296 2
21 TLT-63 FRONT GANG BEAM 3" X 3" X 27" MODEL DH1276 2
MODEL DH1280T971820 2
TLT-163 GANG BEAM 3" X 3" X 33" MODEL DH1280T72020 2
TLT-632 GANG BEAM 3" X 3" X 37" MODEL DH1296T92020 2
TLT-633 GANG BEAM 3" X 3" X 40" MODEL DH1296T72420 2
22 TL15198 5/16" NYLON INSERT LOCK NUT 2
23 TLTPB PILLOW BLOCK HOUSING 8
24 TL2-20138-2 DISC BLADE, 20"X11/8" NOTCHED or *MS
TL2-20138-1 DISC BLADE, 20"X11/8" PLAIN *MS
25 TLT-2 BUMPER WASHER, 1 1/8" - (for front gangs) 2
TLT-OR1 OUTRIGGER WASHER, 1 1/8" - (for rear gangs) 2
26 TLT-1 END WASHER, 1 1/8" 4
27 TLT-698 FLAT WASHER, 1 1/8" 4
28 TLT-18A LOCK NUT, 1 1/8" 4
29 TLT-20 LOCK WASHER, 1 1/8" 4
30 TLT-41 PILLOW BLOCK HANGER 8
31 TLT-714 GANG BEAM STRAP, 2
1
/2"8
32 TL14906 Spacer Spool 1 1/8" X 7
1
/2" MODEL DH1280T72020 *MS
MODEL DH1296T72420 *MS
MODEL DH1280T971820 rear gangs *MS
TL14905 Spacer Spool 1 1/8" X 9" MODEL DH1276 *MS
MODEL DH1296T92020 *MS
MODEL DH1280T971820-front *MS
