* M/S - Model Specific Parts Catalog 14
Parts List (cont’d)
Ref.# Part # Description Qty.
33 TLT-46 End Spacer, 1 1/8"(for 7
1
/2" spacing) MODEL DH1280T72020 *MS
MODEL DH1280T971820 rear *MS
MODEL DH1296T72420 *MS
TLT-48 End Spacer, 1 1/8"
(for 9
1
/2" spacing) MODEL DH1276 *MS
MODEL DH1296T92020 *MS
MODEL DH1280T971820-front *MS
34 TLT-60 BEARING, 1 1/8" 8
35 TLT-740 HEX BOLT, 5/8" X 2" GR. 2 16
36 TLT-13 AXLE 1 1/8" X 31" MODEL DH1276 4
MODEL DH1280T971820 front 2
TLT-133 AXLE 1 1/8" X 34" MODEL DH1280T72020 4
MODEL DH1280T971820 rear 2
TLT-14 AXLE 1 1/8" X 40" MODEL DH1296T92020 4
TLT-141 AXLE 1 1/8" X 41 3/4" MODEL DH1296T72420 4
37 TL15206 CAT. 1 TOP LINK PIN, 3 7/8" USABLE LENGTH 1
38 TL15209 CAT. 1 BUSHING, 1 15/16" 1
39 TL15210 CAT. 2 BUSHING, 1 15/16" 1
40 TLT-744 HEX BOLT, 5/8" X 4
1
/2" GR. 2 1
41 TLVP252 LYNCH PIN 1
42 TL11170 SPACER WASHER, 1 1/8" (if needed) 4
44 TL15194 SAFETY DECAL SHEET(INCLUDES 4 DECALS) 1
TL15220 MODEL DH1276 DECAL(NOT SHOWN) 1
TL15221 MODEL DH1280 DECAL(NOT SHOWN) 1
TL15222 MODEL DH1296 DECAL(NOT SHOWN) 1
TL15195 2 1/2” FRONTIER LOGO DECAL (NOT SHOWN) 3
TL15192 DH12 OPERATOR’S MANUAL (NOT SHOWN) 1
TL15240 4 1/2” RED REFLECTOR(NOT SHOWN) 2
TL15199 9” RED REFLECTOR,Model DH1296(NOT SHOWN) 2
TL15200 9” YELLOW REFLECTOR,Model DH1296(NOT SHOWN) 2
