Frontier PLOTMASTER Series User Manual

DEALERINSTRUCTIONS
Pre‐assembly
Alltractorunitscomecompletelyassembledtothedealer,withtheexceptionoftherear
drag/roller,whichmustbeattachedtotherearofthemachinewiththeprovidedpins.Cutthe
bandingandremovetheunitfromthepallet.Thenremoveanypackingmaterialandensure
thattheadditionalpointsareav
ailable.Ifyouhaveapull‐typehitchmodel,removemachine
fromcrateandinstallthesinglepointhitchandmountingbracketwithsuppliedhardware.
Theninstallthedrag/rollertotherearofthemachine.
DealerChecklist
Inspecttheequipmentthoroughlytobecertainitissetupproperlybeforedeliveringittothe
customer.Thefollowingchecklistisareminderofpointstoinspect.
Checkoffea
chitemifitisfoundsatisfactoryorafterproperadjustmentismade.
____Checktha
tallsafetydecalsareinstalledandingoodcondition.Replaceifdamaged.
____Checkallboltstobesu
retheyaretight.
____Checktha
tallcotterpinsandsafetypinsareproperlyinstalled.
____Thedi
scgangshavebeenpreassembledandmountedtothemainframeatthefactory.It
isimportantforthedealertovisuallycheckandmakesureallpartsareintactpriortodelivery
tocustomer.
____Showcustomerthesaf
e,properprocedurestobeusedwhenmounting,dismounting,and
storingequipment.
____Fo
r3‐pointunits,addwheelweights,ballastinfronttires,and/orfronttractorweightto
enhancefrontendstability.Aminimum20%oftractorandequipmentgrossweightmustbeon
fronttractorwheels.Whenaddingweighttoattain20%oftractorandequipmentweighton
fronttractorwheels,yo
umustnotexceedtheROPSweightcertification.Weighthetractorand
equipment.Donotestimate!
____Showcustomerhowtoma
keadjustments.
____P
resentOperator’sManualandrequestthatcustomerandalloperatorsreaditbefore
operatingequipment.Pointoutthemanualsafetyrules,explaintheirmeaningsandemphasize
theincreasedsafetyhazardsthatexistwhensafetyrulesarenotfollowed.

11
