Mulch Finisher Seeder Specifications
Models #’s
MF1204 MF1206 MF1208
Machine weight 753 lbs 1066 lbs 1242 lbs
Tractor Horsepower
range
30-50 PTO HP 45-75 PTO HP 60-100 PTO HP
Pull-type hitch
Horsepower range
20 (500 CC)-40 N/A N/A
Working width 42” 60” 82”
Unit height 41” 41” 41”
Unit length 54” 74” 74”
Number of blades 6 8 12
Blade diameter 16” 18” 18”
Blade thickness 3 mm 3.5 mm 3.5 mm
Blade spacing 8.25” 7.50” 7.50”
Blade type Notched Notched Notched
Bearing hanger .375 formed plate with
reinforcement
2 - .625 U-bolts per
hanger
.375 formed plate with
reinforcement
2 - .625 U-bolts per
hanger
.375 formed plate with
reinforcement
2 - .625 U-bolts per
hanger
Bearing type 1” square sealed 1” square sealed 1” square sealed
Gang axle 1” square 1” square 1” square
Gang adjustment Pinned Pinned Pinned
Drag width 56” 80” 106”
Roller width 48” 72” 96”
3 point hitch type Cat 1 Cat 1 / 2 Cat 1 / 2
iMatch™ compatible Yes Yes Yes
Single point hitch opt Yes No No
Number of s-tines 3 7 9
1.75 chisel point 3 7 9
9” sweeps 3 7 9
Right turning points 1 3 4
Left turning points 1 3 4
28
