Frontier PLOTMASTER Series - Installation & Removal

Installation&Removal
InstallingPull‐TypeMachineonUtilityVehicle
1.ParkATVorGator.(SeeSAFETYRULESsection.)
2.Placethemachinebehindthevehicle.


MF1204DrawnHitch
3.Placesinglepointhitchontovehicle2”hitchball.Closecouplerandalignthehitchpinholes. 
NOTE:Foroptimumperformance,keepdrawbaraslevelaspossibleduringoperationand
transport(SeeOperatingsection).
4.Installhitchpinthroughholesincoupler.
5.Securespringlockingpinthroughho
leinhitchpin.
6.Atta
chwiringclipstovehiclebattery.

13
