OperatingtheDiskGangs
CAUTION:Avoidinjury!Diskbladesaresharp.Wearglovesand
handlewithcare.Keephandsandfeetawayfromallmovingparts.
Thediskgangshavethreeangleadjustments.
FORWARDHOLE:Shallowestanglesetting,useforlightdisking
MIDDLEHOLE:Mediumanglesetting,usefornormaldisking
REARHOLE:Sharpestanglesetting,useforaggressivedisking

1.Removespringlockpin(A)andpulloutangleadjustmentpin(B).
2.Pushorpulldiskgangstodesiredposition.Re‐installpin(B)and(A).
