SelectingtheOperatingPositionsoftheS‐Tines
CAUTION:Avoidinjury!Donotmakeadjustmentsunlessthe
machineisinstalledonatractororutilityvehicle.
KeephandsandfeetawayfromdisksandS‐tineswhenloweringtothe
ground.
AdjustS‐tinetoolbarupanddownbyslidingitwithintheframereceiversandlockingitin
placeusingpins(A)andlockingclips.
TRANSPORTANDOPERATEHIGH(B)‐UsebottomholetoraiseS‐tinesoutoftheground.
OPERATEMEDIUM(C)‐UsemiddleholeforminimumS‐tinepenetration.
OPERATELOW(D
)‐UsetopholeformaximumS‐tinepenetration.
