3.07 - Front Wheels Adjustment
Upon request the machine can be adapted with two front depth control gauge wheels
(see fig. 7) which are mounted on the side wheel support. These wheels have the same
function as the front roller, allowing the machine to follow the ground contour. They also
should be used with the tractor three point in the float position.
The depth is controlled by raising or lowering the wheels in the wheel supports attached
to the side of the aerator-overseeder. When using, be sure both wheels are in the same
position.
The rear roller is then adjusted so the machine is working as level and parallel to the
ground as possible.
3.08 - Hopper Adjustment
The aerator-overseeder hopper capacity is 5.30 cu.ft. The hopper runs the entire width
of the machine and has a continuously rotating ground driven agitator to breakup clods
and ensure free flow through the distribution system. On the bottom of the hopper are 8
OPERATION 16 FRONTIER
A
ERATOR-OVERSEEDER OPERATOR’S MANUAL
1
2
3
Fig. 7
1. side plate
2. wheel support
3. front wheel
Fig. 8
Seed calibration handle
