Manual of Two-Way Radio System www.FrSky-rc.com P3of9
5.2 Transmitter module specifications:
Model: DFT, DJT
Operating Voltage Range: 6.0V-13.0V
Operating Current: 50mA
Output Power: 60mW
Resolution: 3072
Important!
The effective range of control refers to the distance between the transmitter and the
receiver clear of obstruction. All data was tested and verified by FrSky.
However this is not guaranteed due to many factors such as the flying environment
and the weather, which can greatly affect the effective range of control.
It is extremely important to range check your models prior to each flying
session!
6. How To Use
6.1 Setup
6.1.1 Installation of the transmitting module:
a) Remove the original transmitting module.
b) Put the FrSky 2.4GHz transmitter module into the module port of your RC
transmitter and screw on the transmitting antenna.
c) Check the MODE switch to its corresponding position.
Mode
Switch 1
Switch 2
Mode
1
OFF
OFF
Two-way Mode
2
OFF
ON
V8 Mode
3
ON
OFF
Not Defined
4
ON
ON
Firmware Upgrade
d) Turn the transmitter power on and check the LED status on the module.
