Curtis-Toledo Rotary Compressor CAP862
Operations and Maintenance Manual
Chapter 2 Page 3
Electrical (cont.)
All internal wiring has been done at the factory. Wiring of the power supply to the
compressor should be done by a qualified electrician to comply with the National Electric
Code, state code, and any local codes in accordance with the wiring diagram specific to
your compressor model shown in the included wire diagram.
Chart of Unit Amp Draw
Figure: 2-2
Model 200 V 230 V 460 V 575 V
SE25 Amp Draw 102.6 89.2 44.6 35.5
SE30 Amp Draw 120 104.2 52.1 41.7
SE40 Amp Draw 156.9 136 68 53.7
Failure to properly ground compressor package could result in controller
malfunction.
