FScurtis SE50 - SE Series Specifications

Curtis-Toledo Rotary Compressor CAP862
Operations and Maintenance Manual
Chapter 4 Page 5
D SE Series Screw Air Compressor Specification
Model
Item
SE20 SE25
Operating Pressure
psig
bar
100
6.9
125
8.6
150
10.3
175
12.1
100
6.9
125
8.6
150
10.3
175
12.1
Capacity
cfm
m
3
/min
88
2.5
78
2.2
69
2.0
63
1.8
110
3.1
100
2.8
90
2.5
80
2.3
Discharge Temp.
°F
Ambient temperature+27°
Pressure relief
valve setting
PSIG
Setting pressure 200 psi
Power
hp
kw
20
15
25
18.5
Enclosure
TEFC
Main Motor Speed
rpm
1755 1760
Fan Motor Power h.p. / kw
1 / 0.75 1 / 0.75
Starter
Y- ∆
Voltage
Volt
200/230/460/575V, 3PH, 60HZ
Frequency
Hz
60
Length
in (mm)
44 ½ (1130) 44 ½ (1130)
Width
in (mm)
33 ⅜ (848) 33 ⅜ (848)
Height
in (mm)
51 ¼ (1302) 51 ¼ (1302)
Weight
lb (kg)
1256 (570) 1300 (590)
Discharge outlet inch
1” :PT 1” :PT
Oil Capacity Gal(l)
4 (15.25) 4 (15.25)
System
Motor
Dimension
