Audio Menu
Main Menu Audio
Function SDI 1 Audio Digital CH1&2
Scopes & Audio Meters SDI 2 Audio Digital CH1&2
Video Component Audio Analog
Audio CVBS Audio Analog
Marker DVI-D Audio Analog
System DVI-A Audio Analog
Alarm Audio Sync Signal Clock
OSD Audio Lockout Off
GPI
Display Alignment
System Status
Support
SDI 1 Audio
Allows you to select what audio source should be active (audible) when SDI 1 is the selected video input. You may select
any single channel or stereo pair of embedded audio (i.e. Digital Channel 1, 1&2, 3&4, etc.), Analog Audio (from minijack
input), or No Sound. The active stereo pair selected here will be the stereo pair shown when the Audio Phase Meter is
activated on the SDI 1 Input.
SDI 2 Audio
Allows you to select what audio source should be active (audible) when SDI 2 is the selected video input. You may select
any single channel or stereo pair of embedded audio (i.e. Digital Channel 1, 1&2, 3&4, etc.), Analog Audio (from minijack
input), or No Sound. The active stereo pair selected here will be the stereo pair shown when the Audio Phase Meter is
activated on the SDI 2 Input.
Component Audio
Allows you to select between Analog Audio input (via minijack connector) or No Sound when Component Video is the
selected video input.
CVBS Audio
Allows you to select between Analog Audio input (via minijack connector) or No Sound when Composite Video is the
selected video input.
DVI-D Audio
Allows you to select between Analog Audio input (via minijack connector) or No Sound when DVI-Digital is the selected
video input. On monitors shipped AFTER October 27th, 2014 you can also use the Channel 1 & 2 selection listed here for
stereo HDMI audio support when using a HDMI or Display Port to DVI cable.
DVI-A Audio
Allows you to select between Analog Audio input (via minijack connector) or No Sound when DVI-Analog is the selected
video input.
Audio Sync
Choose between Signal Clock or Internal Clock for Audio Sync. Some embedded audio sources may have a poor quality
signal clock that may lead to audio distortion. Switching to Internal Clock can help to eliminate or minimize such distortion.
Audio Lockout
When set to On this feature will lock the volume, which retains the last used audio setting used. While On, no adjustments
to Audio volume will be possible.
