FSI AM210 - Menu Navigation; System Status

© 2015 Flanders Scientic, Inc.
7
Return to Table of Contents
Menu Navigation / System Status
Main Menu
Pressing the MENU button on the monitor’s keypad will call up the On Screen Menu.
Main Menu Function
Function F1 Scopes & Audio Meters 1
Scopes & Audio Meters F2 Scopes & Audio Meters 2
Video F3 Scopes & Audio Meters 3
Audio F4 Marker 1
Marker F5 Measurement (10Bit)
System Function Display Off
Alarm
OSD
GPI
Display Alignment
System Status
Support
Navigating the Main Menu
To navigate the Main Menu simply use the UP and DOWN keys to highlight a category and press the ENTER button to select
the highlighted sub menu. Navigate the sub menu in the same way by using the UP and DOWN keys to highlight a particular
function and press ENTER to toggle between that function’s settings. To back out of a menu or sub menu, press the LEFT
button. To exit the menu simply press the MENU button.
System Status
The System Status category does not contain any congurable settings, but does provide important information regarding
your monitor’s serial number, rmware version, & current conguration.
Main Menu System Status
Function Input DVI-D
Scopes & Audio Meters Input Mode 1080p 60hz
Video Volume 16
Audio Contrast 0
Marker Brightness 0
System Chroma 0
Alarm Hue 0
OSD IP Address 000.000.000.000
GPI Model AM210
Display Alignment Version 1.0.00-1976
System Status S/N MA210A0000
Support
Note that pressing an input button will temporarily call up a secondary system status summary window that will indicate
incoming signal resolution and frame rate, active color space selected on Display Alignment menu, gamma response
selected on Video Menu, & color matching function selected on Display Alignment Menu*.
*Color Matching Function toggle only works on OLED units, all other units currently use CIE 1931 CMF only.
