EQUIPMENT DRAWINGS & PARTS
74
ITEM # PART # DESCRIPTION
1
FA2 1¼" A-SIDE STRATOFLEX ASSEMBLY
2
FAB3 ½" FEMALE STRATOFLEX FITTING
3
FA4
1¼
"
FEMALE STRATOFLEX FITTING
4
FB4 1¼" MALE STRATOFLEX FITTING
5
FAB5 1¼" MPT x ¾" MPT
6
FAB6 ¾" MPT x ½" MPT
7
FAB7T ¾" FILTER TOP
8
FA7-1T 1" FILTER TOP
9
FAB7 FILTER CANISTER
10
FAB8
FILTER SCREEN
10
FAB10
FILTER HOUSING O-RING
11
FAB11
FILTER SCREEN O-RING
12
FA12
A-SIDE TEMPERATURE GAUGE
13
FB12
B-SIDE TEMPERATURE GAUGE
14
FAB17
¾
"
MPT x ¾
"
FPT TEE
15
FAB14
¾
"
MPT x ¾
"
MJIC
16
G6-1
¼
"
x 20 x 1 ALLEN BOLT
17
FAB19
¾" MPT x 3/8" I.D. SWAGELOK (INCLUDES NUT AND FERRULES)
18
FAB20
¾
"
MPT PLUG (FOR 45’L SLUG GUNS W/ HEAT TAPE)
19
FAB5-1
¾
"
HEX NIPPLE
FILTER ASSEMBLY PARTS
