6
Outdoor type
Hot gas type (Gas at over 150°C and up to 250°C)
Structure
modifications
Special orientation of discharge flange
Different voltage
Special
specifications
Motor modifications
Enhanced-safety, pressure-resisting or explosion-proof
type, corrosion resisting type and high efficiency type
*2： As model KTS is made of stainless steel, only acid pickling is available without
coating.
(2) Standard and special accessories
Standard accessories Special accessories
Companion flange Vibration insulating base
Shaft seal Vibration insulating liner
Suction wire mesh Foundation bolt
Suction damper Expansion joint
Discharge wire mesh *3 Filter
- Silencer
-
Cable gland for outdoor use
*
4
*3: Provided only with models KT-010S/010T/020S/020T.
*
4: If the models KT-010S/010T/020S/020T/040S/040T/100T are used outdoors,
connect a cable gland for outdoor use to the terminal box of the motor, and
carry out wiring with a cable for outdoor use.
Also use a cable with suitable outer diameter to the cable gland.
(It also applies to heat-resistant products.)
3. Placement and installation
3.1 Before using the fan
When you receive the fan, check the following points first.
If there are any problems, contact the sales agent you purchased the product from.
Handle the motor according to the instruction manual of the motor.
Incorrect handling may result in an accident or failure.
(1) Check the nameplate to verify that the unit is the one you ordered.
In particular, check the information on the rated current (50Hz or 60Hz).
(2) Check if the orientation of discharge flange and direction of rotation are as ordered.
(3) All the accessories that you ordered have been delivered.
(4) No part of the product is damaged during transportation.
(5) All fastening parts including bolts and nuts are securely tightened.
