USING YOUR FLLUID
Front Suspension Adjustment
Fork Lock
- The lever (1) locks the suspension.
- To lock the front suspension rotate the
lever (1) toward LOCK.
Preload Adjustment
1. Unscrew the valve cap (2). Screw a fork
/ damper pump onto the valve (3).
2. Inate the fork to the desired pressure.
Never exceed the recommended maxi-
mum air pressure. Stick to the table below.
3. Seated in the normal riding position on
the bike check the "sag". Add or remove
air as needed. You can lean against a
wall to sit with feet on the pedals to set
the "sag".
Recommended air pressure psi / bar
XCR-air
Rider Weight
Pounds
psi bar
<120 40-55 2,7-3,8
120-145 55-65 3,8-4,5
145-165 65-75 4,5-5,2
165-190 75-85 5,2-5,9
190-210 85-100 5,9-6,8
210> 100+ 6,8+
Factory
settting
100 6,8
Max. Pressure 160 11
1
2
3
