MAINTENANCE
Checking the battery fuse
- Open the cover (4) on the battery and
replace the fuse (5).
- When replacing the fuse, ensure that
it is correctly seated.
- Installation is the reverse order.
Checking the Battery Fuse
Replacing a fuse
NOTE
If necessary, remove the upper battery (1)
or the lower battery (2).
The batteries are secured to the frame
with a lock.
- Insert key (3) and while supporting the
battery turn to the left.
- Swing the battery (1) outwards and
remove.
CAUTION
Never use a higher rated fuse or repair
the fuse. Improper handling can destroy
the entire electrical system!
If the fuse blows for no apparent reason,
please contact a local workshop / autho-
rized partner.
NOTE
If blown replace with a 15A blue mini car
fuse (2 pieces are in the battery).
1
1
3
2
4
5
