Replacing Consumables
71
Maintenance
3
4 Rotate the booklet staple cartridge at an
angle.
5 Lift the booklet staple cartridge out of the
unit.
6 With holding the tabs, return new cartridge to
the original position, and then gently push
the cartridge in until it clicks into place.
7 Return the unit to the original position.
8 Close the finisher front door.
Note • If the finisher front door is not completely closed, a message will appear and the machine will
remain paused.
