Paper Jams
91
Troubleshooting
6
2) Remove the jammed paper.
3) Replace the tab.
8 Press down the levers on both sides of the
fusing unit.
9 Close the rear cover.
10 Insert the Tray 1 into the machine, and push
until it stops.
Important • Do not use excessive force on the tray. Doing
so could damage the tray or the inside of the
machine.
11 Insert the Tray 5 (bypass) into the machine,
push until it stops, and close it.
To Next Page
