Changing the Paper Size
57
Paper and Other Media
2
3
Open the end guide (1) and unscrew the screw
(2). Then remove the guide from the tray.
4
Insert the small protrusions at the bottom of the guide into holes corresponding to the
paper size (1). Insert a screw into a hole corresponding to the paper size on the top of the
guide and tighten up the screw (2).
5
Unscrew the screw of the front guide and
remove the guide from the tray.
6
Insert the small protrusions at the bottom of the guide into holes corresponding to the
paper size (1). Insert the screw into a hole corresponding to the paper size on the top of the
guide and tighten up the screw (2).
To Next Page
