421
Problem Solving
15
Text or ima
ges
are pri
nted at an
angle.
The pa
per
guides
in the pa
per
tray are no
t set in the co
rrect
positions.
Adjust the horizontal an
d vertical paper
guides to the
correct po
sitions.
Refer to "Loading Paper" (P.47).
Symptom
Cause
Remedy
420
422
Table of Contents
Table of Contents
3
1 Before Using the Machine
15
Preface
16
Types of Manuals
17
Using this Guide
18
Organization of this Guide
18
Conventions
19
Interface Cables
21
Using the USB Interface
21
Using the Ethernet Interface
22
Power Saver Mode
24
Changing the Interval for Entering Power Saver Mode
24
Customizing the Control Panel
26
Changing the Screen Default
26
Setting the Screen after Auto Clear
27
Customizing the Button Layout
28
Assigning Services to the Custom Buttons
32
Adjusting Screen Brightness
34
Touch Screen
35
Important Security Instructions
37
Entering Text
38
2 Paper and Other Media
39
Paper Types
40
Loadable Quantity and Weight for Supported Paper
40
Supported Paper Type
42
Usable Paper
44
Loading Paper
47
Loading Paper in Trays 1 and 2
47
Loading Tab Paper in Trays 1 and 2
48
Loading Paper in Tray 3
49
Loading Paper in Tray 4
49
Loading Paper in Tray 5 (Bypass)
50
Loading Tab Paper in Tray 5 (Bypass)
51
Loading Paper in Tray 6 (HCF (A4 1 Tray)) (Optional)
52
Loading Paper in Trays 6 and 7 (HCF (A4 2 Tray)) (Optional)
53
Loading Paper in Tray T1 (Inserter) (Optional)
53
Loading Tab Paper in Tray T1 (Inserter) (Optional)
54
Changing the Paper Size
55
Changing the Paper Size for Trays 1 and 2
55
Changing the Paper Size for Tray 6 (HCF (A4 1 Tray)) (Optional)
56
Changing the Paper Size for Trays 6 and 7 (HCF (A4 2 Tray)) (Optional)
58
Changing the Paper Settings
60
3 Maintenance
63
Replacing Consumables
64
Replacing Toner Cartridges
66
Replacing Waste Toner Container
68
Replacing Staple Cartridge (for C3 Finisher or C3 Finisher with Booklet Maker)
70
Replacing Staple Cartridge (for D2-Staple-Finisher or D2-Staple-Finisher with Booklet Maker)
71
Replacing Booklet Staple Cartridge (for C3 Finisher with Booklet Maker)
73
Replacing Booklet Staple Cartridge (for D2-Staple-Finisher with Booklet Maker)
75
Emptying the Hole Punch Waste Container (for C3 Finisher, C3 Finisher with Booklet Maker, D2-Staple-Finisher or D2-Staple-Finisher with Booklet Maker)
77
Replacing the Staple Waste Container (for D2-Staple-Finisher or D2-Staple-Finisher with Booklet Maker)
78
Cleaning the Machine
81
Cleaning the Exterior
81
Cleaning the Touch Screen
82
Cleaning the Document Cover and Document Glass
82
Cleaning the Narrow Glass Strip and Document Presser
82
Cleaning the Document Feeder Rollers
83
Printing a Report/List
85
Deleting a Private Charge Print Job with an Invalid User ID
86
Setting Restore Tool
87
4 Machine Status
89
Overview of Machine Status
90
Machine Information
91
General Information
91
Paper Tray Status
92
Print Reports
92
Printer Reports
94
Fax Reports
97
Automatically Printed Reports/Lists
101
Overwrite Hard Disk
102
Print Mode
102
Fax Receiving Mode
104
Press the <Machine Status> Button
104
Faults
106
Supplies
107
Billing Information
108
On the [Machine Information] Screen
108
User Account Billing Information
109
5 Tools
111
System Settings Procedure
112
Step 1 Entering System Administration Mode
112
Step 2 Entering the System Administrator User ID and Passcode
112
Step 3 Selecting [Tools]
113
Step 4 Selecting a Setting Item on the [Tools] Screen
113
Step 5 Setting a Feature
115
Step 6 Exiting System Administration Mode
115
Tools Menu List
116
Common Service Settings
131
Machine Clock/Timers
131
Power Saver Settings
133
Audio Tones
135
Screen/Button Settings
136
Default Language
137
Paper Tray Settings
141
Image Quality Adjustment
143
Reports
144
Maintenance
146
Delete All Data
147
Finisher Adjustment
147
Software Options
147
Watermark
148
Secure Watermark
150
Digital Codes Settings
151
Force Secure Watermark
151
Secure Watermark Control
151
Force Annotation
153
Print Universal Unique ID (Apeosport Series Models Only)
154
Image Log Control (Apeosport Series Models Only)
155
Notify Job Completion by E-Mail
157
Plug-In Settings
157
Other Settings
158
Encryption Key for Confidential Data
165
Software Download
166
Copy Service Settings
168
Copy Tab - Features Allocation
168
Preset Buttons
169
Copy Defaults
169
Image Rotation
171
Original Orientation
171
Copy Output
171
Copy Control
173
Original Size Defaults
175
Reduce/Enlarge Presets
176
Annotations - Create Comments
176
Connectivity & Network Setup
177
Port Settings
177
Port 9100
179
Smb Client
179
Protocol Settings
182
Machine's E-Mail Address/Host Name
186
Proxy Server Settings
187
EP Proxy Server Setup
188
SIP Settings
189
T.38 Settings
192
Outgoing/Incoming E-Mail Settings
193
Remote Authentication/Directory Service
194
Security Settings
199
Certificate Revocation Retrieval Settings
203
Other Settings
204
Print Service Settings
206
Allocate Memory
206
Delete Form
207
Other Settings
208
Banner Sheet
210
Scan Service Settings
212
Screen Defaults
212
Scan Defaults
213
Searchable Text
215
Language of the Original
215
Scan to PC Defaults
216
Original Size Defaults
216
Output Size Defaults
217
Reduce/Enlarge Presets
217
Other Settings
217
Background Suppression Level
218
Color Space
218
Image Transfer Screen
218
Shadow Suppression Level
218
Tiff Format
218
Fax Service Settings
221
Screen Defaults
221
Fax Defaults
222
Fax Control
223
Maximum Stored Pages
228
Memory Full Procedure
228
Fax Received Options
229
Local Terminal Information
231
Original Size Defaults
231
Reduce/Enlarge Presets
231
Internet Fax Control
233
E-Mail/Internet Fax Service Settings
236
E-Mail Control
236
Address Book Settings
239
Folder Service Settings
240
Job Flow Service Settings (Apeosport Series Models Only)
242
Media Print Service Settings
243
Stored File Settings
244
Web Applications Service Setup (Apeosport Series Models Only)
247
Server Certificate Verification Settings
247
Server Setup
249
Other Settings
250
Web Browser Setup
251
Setup
253
Create Folder
253
Stored Programming
255
Create Job Flow Sheet
255
Restrictions on Using Job Flow
256
Create Job Flow Sheet Keyword
264
Add Address Book Entry
264
Given Name
267
Fax Number
269
Starting Rate
269
Delay Start
270
Relay Broadcast
270
Create Fax Group Recipients
271
Add Fax Comment
272
Paper Tray Attributes
273
Accounting
274
Create/View User Accounts
274
User Name
275
View Accounts
277
Reset User Accounts
278
System Administrator's Meter (Copy Jobs)
279
Accounting Type
279
Accounting Login Screen Settings
280
Fax Billing Data
281
Accounting/Billing Device Settings
281
Authentication/Security Settings
284
System Administrator Settings
284
Authentication
285
Login Type
285
Access Control
286
Create Authorization Groups
287
Create/View User Accounts
287
Reset User Accounts
287
User Details Setup
288
Maximum Login Attempts by System Administrator
290
Passcode Policy
290
Charge/Private Print Settings
291
Receive Control
291
Allow User to Disable Active Settings
293
Job Status Default
293
Overwrite Hard Disk
294
