Stapler Faults
595
Problem Solving
15
7 Slightly push the booklet staple cartridge
upwards, and make sure that it clicks into place.
Note • Return the booklet staple cartridge until ( )
of the booklet staple cartridge is fitted in
( ) of the booklet unit.
8 Return the booklet unit to its original position.
9 Close the finisher front door.
Note • If the door is not closed completely, a message appears and the machine will remain paused.
If you cannot remove jammed staples even after you perform the above procedure, contact
our Customer Support Center.
Staple Jams in Staple Cartridge
(for D2-Staple-Finisher or D2-Staple-Finisher with Booklet Maker)
The following describes how to clear staple jam occurred in the staple cartridge of the D2-
Staple-Finisher (optional) and the D2-Staple-Finisher with Booklet Maker (optional).
This section describes the procedure to remove the jammed staples in the D2-Staple-
Finisher with Booklet Maker, as an example. You can apply the same procedure to the D2-
Staple-Finisher.
1 Make sure that the machine is not operating,
and open the finisher right door.
2 Grasp the Handle [R1] of the staple cartridge
holder, and pull out the holder towards you.
To Next Page
