Fold Position Adjustment
633
Appendix
16
6 Enter the value you measured in step 5 in
[Values A & B Before Adjustment], and the
value to which to adjust in [Desired Values A &
B].
Important • Set value B so that an edge of the paper does
not extend beyond a fold position of the
paper. Extending an edge of paper beyond a
fold position of the paper may cause a paper
jam.
7 Select [Adjust].
8 Select [Sample Printout] again.
9 Select the tray in which you loaded paper, and press the <Start> button.
The sample is printed.
10 Select [Close].
11 Confirm the result of sample printout.
12 Adjust the alignment again if necessary. (Step 5 to 11)
13 Select [Save].
14 Select [Close] until the Services Home screen is displayed.
Note • When you configure settings under [System Settings] or [Setup] and then press the <Services Home>
button, the screen directly goes back to the Services Home screen.
