HP-GL/2 Emulation
677
Appendix
16
Examples of Combinations of Each Function
The following are examples showing the print results that can be achieved by combining
various functions.
îš„ Document: Auto, Coordinate Origin: 0 Degrees, Scaling Mode: Paper Size, Scaling: ON
îš„ Document: Auto, Coordinate Origin: 0 Degrees, Scaling Mode: Paper Size, Scaling: OFF
îš„ Document: Auto, Coordinate Origin: 0 Degrees, Scaling Mode: Active Coordinate Area,
Scaling: ON
Print Area
Document Size
Paper Size
Print Area
Document Size Paper Size
Print Area
Active
Coordinate Area determined by entered data
Paper Size
To Next Page
