16 Appendix
668
Appendix
16
Folding/180
degree rotation
168 Specify the Z fold half sheet and whether to rotate landscape documents in
180 degrees.
[0] (Default) : None
[1] : Z fold half sheet (Right bind/Top bind)
[2] : Z fold half sheet (Left bind/Bottom bind)
[3] : None (180 degrees rotation)
[4] : Z fold half sheet (Right bind/Top bind, 180 degrees rotation)
[5] : Z fold half sheet (Left bind/Bottom bind, 180 degrees rotation)
Emulation target
printer
169 Select the machine to emulate.
[0] (Default) : HP750
[1] : FX4036
Pen attributes 800-815
(Pen width)
(No. 0-No.15)
Set the width (thickness of the line) of the 16 pens (No. 00 to 15). You can set
the width from 0.0 to 25.5 mm in 0.1 mm increments. No. 00 denotes Item
No. 800.
[0] - [255] (Default: 3) : 0 to 25.5 mm
Note • If the image is reduced by concern with the relationship between
[Document size] and [Paper size] settings, the pen width is reduced
accordingly to 0.1 mm at the smallest.
• The width of the line gets thick symmetrically with respect to the center of
the line.
• If the width is set to 0.0 mm, nothing is plotted.
850-865
(Line end
shape)
(No. 0-No.15)
Set the line end shape of the 16 pens (No. 00 to 15). No. 00 denotes Item No.
850.
[0] (Default) : Cut
[1] : Round
[2] : Rectangular
[Cut]
: specified coordinate
[Round]
: specified coordinate
[Rectangular]
: specified coordinate
Parameter Item No. Value
